| Standby kVA | 33 kVA |
| Standby kW | 26 kW |
| Standby Current | 48 A |
| Prime kVA | 30 kVA |
| Prime kW | 24 kW |
| Prime Current | 43 A |
| Frequency | 50 Hz |
| Voltage | 400/230V, 3-Phase |
| Power Factor | 0.8 lagging |
| Make & Model | Perkins 1103A-33G |
| Optional Engine | Cummins 4BT3.9-G11 |
| Cylinders | 3 In-Line |
| Displacement | 3.3 Liters |
| Bore × Stroke | 105 × 127 mm |
| Aspiration | Naturally Aspirated |
| Make & Model | Leroy Somer FGL20030 |
| Options | Stamford UCI224C / Mecc Alte ECP32-1S |
| AVR | Digital R450 |
| Voltage Regulation | ±1% |
| Controller | Auto Mains Failure (AMF) |
| Controller Model | DSE 7320 MKII Co |
| Fuel Tank | 90 Liters L |
| Runtime @ 75% | 16.1 Hours |
| Cooling | Water-Cooled, Radiator Mounted |
| Max Ambient | 40°C |
| Open Frame (L×W×H) | 1570×760×1231 |
| Open Frame Weight | 660 kg |
| Silent Canopy (L×W×H) | 2300×950×1240 |
| Silent Canopy Weight | 1140 kg |
Enclosure, ATS, fuel system and controls configured to your specification.
